Introducing Easyflex 3/4” ID FIP x MIP water heater connectors with three available lengths – 12″, 15,” 18″, and 24″. These connectors are built to last with stainless-steel 304 tubing, chrome plated brass connection nuts, and high-quality EPDM gaskets. They are UPC certified and rigorously tested for optimal performance.
| ID | Part # | Description | Qty/Box |
| 3/4″ | EFWC-034-SS-1011-12 | 3/4″ FIP x 3/4″ MIP, 12″ | 25 |
| 3/4″ | EFWC-034-SS-1011-15 | 3/4″ FIP x 3/4″ MIP, 15″ | 25 |
| 3/4″ | EFWC-034-SS-1011-18 | 3/4″ FIP x 3/4″ MIP, 18″ | 25 |
| 3/4″ | EFWC-034-SS-1011-24 | 3/4″ FIP x 3/4″ MIP, 24″ | 25 |
| ID | Part # | Description | Qty/Box |
| 3/4″ | EFWC-034-SS-1013-15 | 3/4″ FIP x 1-1/4″ MIP, 15″ | 25 |
| 3/4″ | EFWC-034-SS-1013-18 | 3/4″ FIP x 1-1/4″ MIP, 18″ | 25 |
| 3/4″ | EFWC-034-SS-1013-24 | 3/4″ FIP x 1-1/4″ MIP, 24″ | 25 |
| Tubing | Stainless Steel 304 (ASTM A240) | ||||
| Tubing Thickness | 0.01″ and 0.012″ | ||||
| Fittings | Chrome-Plated Brass 3771 | ||||
| Gasket | High-Quality EPDM | ||||
| Lengths Available | 12″, 15″, 18″, 24″ | ||||
| Sizes Available (ID) | 3/4″ | ||||
| Thread Standard | ASME B1.20.1 | ||||
| Working Pressure | Up to 125 psig | ||||
| Intermittent Impulse Pressure | Up to 180 psig | ||||
| Temperature Rating | -40° F to 180° F (-40° C to 82° C) | ||||
| Minimum Bend Radius | 2.5″ (Recommended) | ||||
